113.13 Series 1.5" ABS Hydraulic Pressure Gauge, Liquid Filled, Brass Wetted Parts
Manufacturer: Wika Instrument Lp
Mfg Product Code:
111.13 Series 1.5" Hydraulic Pressure Gauge
The Wika 111.13 Series Hydraulic Pressure Gauge is the ideal solution for measuring points experiencing high dynamic pressure loads or vibrations. Designed for both gaseous and liquid media that are neither highly viscous nor crystallizing, and are compatible with copper alloy parts, this gauge excels in a variety of applications, including hydraulics and compressors.
Engineered with exceptional vibration and shock resistance, the Wika 111.13 Series ensures reliable and accurate readings even in the most demanding environments. Its robust design adheres to both EN 837-1 and ASME B40.100 standards, underscoring its quality and precision. The gauge is available in three nominal sizes—40 mm (1 ½"), 50 mm (2"), and 63 mm (2 ½")—offering versatility to meet specific measurement needs. It covers a broad range of scale measurements up to 400 bar (6,000 psi), making it suitable for a wide array of industrial applications.
For those seeking a reliable and durable hydraulic pressure gauge, the Wika 111.13 Series stands out. Branom is renowned for offering top-notch industrial products, and the Wika 111.13 Series Hydraulic Pressure Gauge is no exception. With its superior construction and design, this gauge ensures optimal performance and longevity, making it a valuable addition to any professional toolkit. Choose Branom for your purchase to ensure you are getting the best quality and service in the industry.
Order Code Prefix: 113.13-A-
Specifications
| Wika 113.13A | |
|---|---|
| Scale Range | ￭ psi ￭ or [PG310] 0/15 psi or [PG321] 0/30 psi or [PG341] 0/60 psi or [PG369] 0/100 psi or [PG410] 0/150 psi or [PG411] 0/160 psi or [PG414] 0/200 psi or [PG417] 0/250 psi or [PG421] 0/300 psi or [PG428] 0/400 psi or [PG434] 0/500 psi or [PG441] 0/600 psi or [PG455] 0/800 psi or [PG469] 0/1000 psi or [PG510] 0/1500 psi or [PG514] 0/2000 psi or [PG521] 0/3000 psi or [PG528] 0/4000 psi or [PG534] 0/5000 psi or [PG541] 0/6000 psi or ￭ psi / inHg ￭ or [PV310] -30 inHg/0 psi or [PV321] -30 inHg/15 psi or [PV331] -30 inHg/30 psi or [PV352] -30 inHg/60 psi or [PV379] -30 inHg/100 psi or [PV412] -30 inHg/160 psi or [PV415] -30 inHg/200 psi or [PV422] -30 inHg/300 psi or ￭ bar ￭ or [BG310] 0/1 bar or [BG316] 0/1.6 bar or [BG320] 0/2 bar or [BG325] 0/2.5 bar or [BG340] 0/4 bar or [BG360] 0/6 bar or [BG370] 0/7 bar or [BG410] 0/10 bar or [BG414] 0/14 bar or [BG416] 0/16 bar or [BG420] 0/20 bar or [BG425] 0/25 bar or [BG430] 0/30 bar or [BG440] 0/40 bar or [BG460] 0/60 bar or [BG470] 0/70 bar or [BG510] 0/100 bar or [BG514] 0/140 bar or [BG516] 0/160 bar or [BG520] 0/200 bar or [BG525] 0/250 bar or [BG532] 0/315 bar or [BG540] 0/400 bar or ￭ bar vacuum ￭ or [BV310] -1/0 bar or [BV316] -1/0.6 bar or [BV320] -1/1 bar or [BV325] -1/1.5 bar or [BV330] -1/2 bar or [BV340] -1/3 bar or [BV350] -1/4 bar or [BV360] -1/5 bar or [BV380] -1/7 bar or [BV410] -1/9 bar or [BV411] -1/10 bar or [BV416] -1/15 bar or [BV425] -1/24 bar or [BV431] -1/30 bar or ￭ kPa ￭ or [LG270] 0/70 kPa or [LG310] 0/100 kPa or [LG316] 0/160 kPa or [LG320] 0/200 kPa or [LG325] 0/250 kPa or [LG330] 0/300 kPa or [LG340] 0/400 kPa or [LG360] 0/600 kPa or [LG370] 0/700 kPa or [LG380] 0/800 kPa or [LG410] 0/1000 kPa or [LG414] 0/1400 kPa or [LG416] 0/1600 kPa or [LG425] 0/2500 kPa or [LG430] 0/3000 kPa or [LG440] 0/4000 kPa or [LG460] 0/6000 kPa or [LG470] 0/7000 kPa or [LG480] 0/8000 kPa or [LG510] 0/10000 kPa or [LG514] 0/14000 kPa or [LG516] 0/16000 kPa or [LG520] 0/20000 kPa or [LG525] 0/25000 kPa or [LG532] 0/31500 kPa or [LG540] 0/40000 kPa or ￭ kPa vacuum ￭ or [LV310] -100/0 kPa or [LV316] -100/60 kPa or [LV320] -100/100 kPa or [LV325] -100/150 kPa or [LV330] -100/200 kPa or [LV340] -100/300 kPa or [LV350] -100/400 kPa or [LV360] -100/500 kPa or [LV380] -100/700 kPa or [LV410] -100/900 kPa or [LV411] -100/1000 kPa or [LV416] -100/1500 kPa or [LV425] -100/2400 kPa or [LV431] -100/3000 kPa or ￭ MPa ￭ or [EG310] 0/0.1 MPa or [EG316] 0/0.16 MPa or [EG320] 0/0.2 MPa or [EG325] 0/0.25 MPa or [EG340] 0/0.4 MPa or [EG360] 0/0.6 MPa or [EG370] 0/0.7 MPa or [EG410] 0/1 MPa or [EG414] 0/1.4 MPa or [EG416] 0/1.6 MPa or [EG420] 0/2 MPa or [EG425] 0/2.5 MPa or [EG430] 0/3 MPa or [EG440] 0/4 MPa or [EG460] 0/6 MPa or [EG470] 0/7 MPa or [EG510] 0/10 MPa or [EG514] 0/14 MPa or [EG516] 0/16 MPa or [EG520] 0/20 MPa or [EG525] 0/25 MPa or [EG532] 0/31.5 MPa or [EG540] 0/40 MPa or ￭ MPa vacuum ￭ or [EV310] -0.1/0 MPa or [EV316] -0.1/0.06 MPa or [EV320] -0.1/0.1 MPa or [EV325] -0.1/0.15 MPa or [EV330] -0.1/0.2 MPa or [EV340] -0.1/0.3 MPa or [EV350] -0.1/0.4 MPa or [EV360] -0.1/0.5 MPa or [EV380] -0.1/0.7 MPa or [EV410] -0.1/0.9 MPa or [EV411] -0.1/1 MPa or [EV416] -0.1/1.5 MPa or [EV425] -0.1/2.4 MPa or [EV431] -0.1/3 MPa or ￭ kg/cm2 ￭ or [KG298] 0/1 kg/cm2 or [KG316] 0/1.6 kg/cm2 or [KG320] 0/2 kg/cm2 or [KG325] 0/2.5 kg/cm2 or [KG339] 0/4 kg/cm2 or [KG359] 0/6 kg/cm2 or [KG369] 0/7 kg/cm2 or [KG398] 0/10 kg/cm2 or [KG414] 0/14 kg/cm2 or [KG416] 0/16 kg/cm2 or [KG420] 0/20 kg/cm2 or [KG425] 0/25 kg/cm2 or [KG429] 0/30 kg/cm2 or [KG439] 0/40 kg/cm2 or [KG459] 0/60 kg/cm2 or [KG469] 0/70 kg/cm2 or [KG498] 0/100 kg/cm2 or [KG514] 0/140 kg/cm2 or [KG516] 0/160 kg/cm2 or [KG520] 0/200 kg/cm2 or [KG525] 0/250 kg/cm2 or [KG531] 0/315 kg/cm2 or [KG539] 0/400 kg/cm2 or ￭ kg/cm2 vacuum ￭ or [KV298] -1/0 kg/cm2 or [KV316] -1/0.6 kg/cm2 or [KV320] -1/1 kg/cm2 or [KV325] -1/1.5 kg/cm2 or [KV329] -1/2 kg/cm2 or [KV339] -1/3 kg/cm2 or [KV349] -1/4 kg/cm2 or [KV359] -1/5 kg/cm2 or [KV378] -1/7 kg/cm2 or [KV398] -1/9 kg/cm2 or [KV411] -1/10 kg/cm2 or [KV416] -1/15 kg/cm2 or [KV425] -1/24 kg/cm2 or [KV430] -1/30 kg/cm2 |
| 2nd Scale | [Z] Without or [B] bar or [P] psi or [L] kPa or [E] MPa or [K] kg/cm2 |
| Process Connection | [GA] G 1/8 B or [GB] G 1/4 B or [NH] 1/8 NPT or [NB] 1/4 NPT or [RD] R 1/8-ISO7 (DIN2999) or [RE] R 1/4-ISO7 (DIN2999) |
| Restrictor | [Z] Without or [L] Brass, D 0.3 or [M] Brass, Orifice (0.5mm / 0.02 in) |
| Accuracy Class | [JZZ] +/- 3/2/3% (ASME B40.100 Grade B) or [4ZZ] Class 2.5 |
| Thread Protection | [Z2] Without or [12] With Thread Protection |
| Nominal Size | 1.5" |
| Connector Location | [A] Back Mount |
| Case Material | [SZZL] Black Plastic |
| Mounting Flange / Bracket | [ZL] Without |
| Special Design Features | [Z] Without |
| Case Filling | [A-ZZZC] Glycerin |
| Certificates | [Z] Without |
| Approvals | [Z] Without |
| Additional Ordering Info | [Z] Without |
| Pointer | [C] Standard |
| Packing | [2] Single Packing |
| Gauge Features | |
|---|---|
| *Gauge Brand | Wika |
| *Model | 113.13 |
| *Dial Size | 1-1/2 in (38 mm) |
| *Scale Range | ≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar) |
| *Pressure Type | Gauge Pressure |
| *Measuring Principle | Bourdon Tube |
| *Fill Type | Liquid Filled / Fillable |
| *Product Unit of Measure | psi / inHg, bar, kPa, MPa, kg/cm2 |
| *Process Connection Size | 1/8 NPT, G 1/4 B, G 1/8 B, 1/4 NPT, R 1/4-ISO7, R 1/8-ISO7 |
| *Process Connection Location | Center Back Mount |
| *Wetted Material | Copper Alloy (Brass) |
| *Accuracy | ±3%, ±2% |
| *Case Material | ABS |
| *Window | Plastic, Clear |
| *Dial Material | ABS, White |
| *Pointer Material | ABS, Black |
| *Bezel Material | None |
| *Window Ring | Without |
