111.10 Series 4" Dry Sprinkler Gauge, Brass Wetted Parts
Manufacturer: Wika Instrument Lp
Mfg Product Code:
111.10SP 4" Std Sprinkler Gauge
The Wika 111.10SP Standard Series Sprinkler Gauge is the ultimate solution for fire sprinkler systems, ensuring safety and reliability in critical applications. Designed to work seamlessly with all media that do not obstruct the pressure system or compromise copper alloy components, this gauge stands out in its field for both performance and durability.
A notable feature of this gauge is the NEW FlexWindow option available on the 2-1/2” models, offering enhanced flexibility and usability. The 111.10SP is UL-listed (UL-393) in the United States and Canada, and also boasts Factory Mutual (FM) approval, affirming its adherence to stringent safety and performance standards.
This sprinkler gauge is not only reliable but also economical, providing an affordable option without sacrificing quality. Branom Instrument Co. is proud to offer the Wika 111.10SP Standard Series Sprinkler Gauge, ensuring you receive a top-tier product with unmatched service.
Order Code Prefix: 111.10S-E-
This product is no longer available.
Specifications
| Wika 111.10SP | |
|---|---|
| Scale Range | [AA] 0…80 psi, retard to 250 psi or [AB] 0..300 psi or [AC] 0..400 psi or [AD] 0..600 psi |
| 2nd Scale | [Z] Without or [B] bar or [L] kPa or [K] kg/cm2 |
| Process Connection | [NB] 1/4 NPT or [ND] 1/2 NPT |
| Case Material | [AUEZ] Black Polycarbonate or [ACEZ] Black Steel |
| Accuracy Class | [J-ZZ1Y] ± 3/2/3% (ASME B40.100 Grade B) or [I-ZZ1Y] ± 2/1/2% (ASME B40.100 Grade A) |
| Thread Protection | [Z] Without or [1] With Thread Protection |
| PTFE Tape on Connection | [Z2] Without or [A2] With PTFE Tape |
| Process Connection Surface Area | [A-B] Brass or [E-B] Nickel Plated |
| Serial No. on Dial | [ZU] Without or [1U] Serial Number *...* |
| Color for Outer Scale | [A] Black or [C] Red or [B] White or [D] Blue |
| Color for Inner Scale | [Z1] Without or [C1] Red or [A1] Black or [B1] White or [D1] Blue Pantone 3005 |
| Mark on Dial | [1SZ] Year of Manufacture or [ASZ] Year of Manufacture - *AIR* or [BSZ] Year of Manufacture - *WATER* or [CSZ] Year of Manufacture - *AIR/WATER* or [ESZ] Month and Year of Manufacture - *AIR* or [FSZ] Month and Year of Manufacture - *WATER* or [GSZ] Month and Year of Manufacture - *AIR/WATER* |
| Text for Dial | [#ZZZZZ] AIR/WATER or [ZZZZZZ] Without |
| Manufacturer Logo | [Z2] Without or [22] *WIKA®* |
| Additional Mark | [Z] Without or [J] *Pressure Gauge for Fire Protection Service* |
| Norm-Mark on Dial | [U] *UL & FM* *Assembled in USA* or [Z] Without |
| Nominal Size | 4" |
| Connector Location | [U] Lower Mount |
| Window | [E] Polycarbonate |
| Restrictor | [Z] Without |
| Certificates | [Z] Without |
| Additional Ordering Info | [Z] Without |
| Movement | [1] Copper Alloy |
| Pointer | [Y] Aluminum, Black |
| Packing | [2] Single Packing |
| Dial | [B] Aluminum, White w/Stop Pin |
| Pressure Gauge Standard | [U] US-Standard |
| Dial Background | [1] White |
| Mark Color | [S] Black |
| Arcs / Segments | [Z] Without |
| Logo Options | [ZZZZZ] Without |
| Stop Pin on Dial | [2] At 6 O'Clock |
| Gauge Features | |
|---|---|
| Gauge: Brand | Wika |
| Gauge: Model | 111.10SP |
| Gauge: Dial Size | 4 in (100 mm) |
| Gauge: Scale Range | ≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar) |
| Gauge: Pressure Type | Gauge Pressure |
| Gauge: Measuring Principle | Bourdon Tube |
| Gauge: Fill Type | Dry |
| Gauge: Product Unit of Measure | psi |
| Gauge: Process Connection Size | 1/8 NPT, 1/4 NPT |
| Gauge: Process Connection Location | Lower Mount |
| Gauge: Wetted Material | Copper Alloy (Brass) |
| Gauge: Accuracy | ±3%, ±2% |
| Gauge: Case Material | Polycarbonate, Steel |
| Gauge: Window | Snap-In, Polycarbonate |
